Trailed disk harrows ADP and ADPS

disk harrows are perfect for basic non-moldboard, pre-sowing tillage for crops, and stubble cultivation with crumbling and ploughing plant residues. The ttine rollers hinged on the frame make it possible to roll the treated soil to preserve moisture. The units consist of a two-row frame and tines (cut-out disks Ø 650 mm). Moreover, these elements are on separate tines at a distance of 350 mm from each other.

For the production of tines of tines, seamless pipes of the following sizes are used:

• vertical part – outer Ø 70 mm, wall thickness 12 mm;
• bearing housing – outer Ø 108 mm, wall thickness 18 mm.

The bearing unit of the tine of the working parts is the most critical and highly loaded disk unit part. In our design, we use a one-piece forged axle of a disk of increased diameter, which undergoes HFC hardening and metal grinding during manufacturing. The labyrinth seal of the «disk axis-bearing assembly housing», pair, the high-quality cuffs manufactured by «Eriks» Holland, and a «blind» cover with a rubber seal can reliably protect the assembly from dust, soil particles, etc. The Lutsk Bearing Unit (a part of the Swedish corporation SKF) produces tapered roller bearings 7508 and 7509. They are used for assembly that guarantees high quality that meets the highest international standards.

Replacement of cut-out disks does not need disassembling the bearing assembly. Adjustment of the position of the press roller is convenient due to rearranging the fingers in 2 fixed positions, at the front attachment point and in 9 fixed positions, at the rear attachment point of the road wheel.

Optionally (for an additional fee on the preliminary order of the consumer) are available or installation on the disk units:

• notched disks Ø 660 mm manufactured by Bellota Spain, made of boron steel, highly resistant to abrasion, having a 2-2.5 times longer service life;
• maintenance-free bearing units that do not require periodic adjustment and regular lubrication
• press rollers type STS («ground–on-ground» operation) Ø 530 mm (single or tandem);
• press rollers with stacked spring spherical sectors;
• harrow (spring), which is mounted on the btineets (holders) of the ttine roller and has independent adjustments of the working depth and angle of attack of the spring teeth;
• hitch type CAT.2 (for aggregation using the lower linkage of the tractor hitch).
