Cultivators KRN

Description

Cultivation of row spacing – is one of the operations for intensifying the processing of tilled crops, fruit and berry and other plantations. The implementation of inter-row cultivation during the growing season of crop development, in addition to weed control, also allows for the accumulation and preservation of moisture in the soil, the improvement of the air and nutrient regime for the cultivated crop's development, and the activation of beneficial soil microorganisms.

The tines set of inter-row cultivators KRN – consist of a universal lancet and one-sided flat-cutting shares. Their use allows you to destroy weeds and carry out loosening in the working area.

With the help of cultivators equipped with systems for applying loose (granular) fertilizers, it is possible to carry out inter-row and the root top dressing of cultivated crops simultaneously with the general processing. When using a variety of additional sets of tines, the KRN cultivator allows:

- process potato crops with the help of hilling double-sided buildings;

- loosen the inter-row working area with chisel-shaped shares;

- sprinkle the protective zone between the rows by sprinkling with the use of one-sided shares;

- formation of furrows (for irrigated (irrigated) agriculture)

The cultivators are perfect for processing standard row spacings of 45 and 70 cm, depending on the number of sections of the tines. Also, they can aggregate with tractors of at least 1.4 class.

The standard equipment of KRN cultivators for inter-row cultivation includes:

- the general set of tines;

- parking supports, on which support bearing wheels are installed in the transport position;

- separate two hitches for a standard coupler for transport and operational position.

Additional implements and systems for applying fertilizers and pesticides are optionally available on request at an additional cost.



Main characteristics

Main characteristics of KRN cultivators

PARAMETER NAMEKRN-4,2 (spacing
-70 cm)
KRN-4,2
with SVSU (spacing-70 cm)
KRN-5,6 (spacing
-70 cm)
KRN-5,6 with SVSU (spacing-70 cm)KRN-5,6 (spacing
-45 cm)
KRN-5,6 with SVSU
(spacing
-45 cm)
Capture width, m 4,2 4,2 5,6 5,6 5,6 5,6
Productivity, ha/hour, min 4,2 4,2 5,6 5,6 5,6 5,6
Number of processed rows, pcs. 6 6 8 8 12 12
Number of tines sections, pcs. 7 7 9 9 13 13
Total weight, kg,
max
720 940 900 1130 1130 1130
Number of fertilizer boxes in SVSU, pcs. - 6 - 8 - 6
Fertilizer seeding rate, kg/ha - 65-675 - 65-675 - 50-525
Operating speed
km/h
3-10 3-10 3-10 3-10 3-10 3-10
Processing depth, cm 6-16 6-16 6-16 6-16 6-16 6-16
Dimensions while working, mm,
max

- length 2100 2100 2100 2100 2100 2100
- width 4875 4875 6500 6500 6500 6500
- height 1300 1700 1300 1700 1300 1700
The main set of tines, pcs.
- universal lancet shares (capture 220 mm) 7 7 9 9 13 13

- one-sided flat cutting shares (capture 165 mm)

14 14 18 18 26 26
- chisel-shaped shares with a socket for SVSU - 12 - 16 - 12
